Without Gear
S-SERIES
CAMM Group’s gearless slewing rings, also known as bearing turntables, offer smooth and stable 360-degree rotation without the need for gear-driven torque transmission. Designed for applications where simplicity and precision are key, these slewing rings excel in positioning systems, light industrial machinery, and platforms. With low maintenance and durable performance, they provide an efficient solution for rotational motion.

Features
- Gearless design for smooth and stable rotation
- Available in single, double, and triple row configurations
- Four-point or double four-point contact bearings
- Made from 42CrMo4 / C45 / 50Mn materials
- Hardened raceway (standard up to 54HRC)
- Gear hardening available upon request
- Available in sizes ranging from 100mm to 2,300mm outer diameter (OD)
- Supplied with material and quality certificates
- Corrosion protection options available
Applications
Gearless slewing rings provide a simple yet versatile solution for applications requiring smooth, stable rotation without torque-driven motion. Their design ensures low maintenance and clean operation, making them ideal for positioning systems, robotics, and medical equipment. Perfect for light-duty and precision applications, these slewing rings excel wherever smooth rotation and structural stability are needed.
